H-1370L Computer Numerical Control (CNC)

Features

● High rigidity precision linear guides are selected, featuring high speed, low noise and low wear, which are suitable for the rapid processing of precision mold parts.

● The spindle adopts C3 high-precision lead screw angular contact ball bearings and a high-strength arrangement structure.

● It is driven by a high-torque, low-noise and highly stable AC control servo motor.

● The powerful cutting ability combines with outstanding accuracy and performance, making inlaying and hole drilling operations simple and easy.

● It is widely used in the processing industries of machine tools, auto parts, lighting fixtures, hardware and other parts.

Inquire Now Next Product

Product Description

Features

● High rigidity precision linear guides are selected, featuring high speed, low noise and low wear, which are suitable for the rapid processing of precision mold parts.

● The spindle adopts C3 high-precision lead screw angular contact ball bearings and a high-strength arrangement structure.

● It is driven by a high-torque, low-noise and highly stable AC control servo motor.

● The powerful cutting ability combines with outstanding accuracy and performance, making inlaying and hole drilling operations simple and easy.

● It is widely used in the processing industries of machine tools, auto parts, lighting fixtures, hardware and other parts.

Specifications

Item	unit	H-1370L
Worktable area	mm	1500*700
Worktable maximum loading	kg	900
T-Slot(slotwidthdistance)	mm	5-18*145
Spindle nose taper	BT	BT40/BT50
X/Y/Z axis travel	mm	1300/700/700
Distance between spindle end face and worktable end face	mm	140-840
X, Y, Z axis gauge specifications		45 (six slides)/45 (four rails)/sliding guide rails
Spindle Speed (Belt type/Direct Connection)	rpm	8000
Tool magazine capacity	T	24
X/Y/Zaxis fast displacement	m/min	16/16/14
Cutting feed speed	m/min	1-6000
Repeated positioning accuracy	mm	±0.003/300
Machine weight	Kg	8000

Processable product pictures
